This module serves as a fundamental component within the API Framework, enabling JWT-based authentication for secure access. To incorporate JWT authentication into your API configuration, integrating this module is a necessary step. It provides the foundational mechanisms required for managing and validating JWT tokens, ensuring that only authenticated requests are granted access to protected endpoints.

Overview

JWT (JSON Web Token) authentication provides a robust and stateless way to secure API endpoints. It ensures that only authorized users can access API resources by requiring the client to include a token in the request headers. An Odoo Implementation of RFC 7519. (Thanks to Mr. José Padilla)

How It Works

When accessing an API endpoint secured with JSON Web Token (JWT) authentication, clients need to include an Authorization header in the request, containing the JWT token provided by the server. This token, which serves as proof of authentication, is typically issued during the initial login process. Once authenticated, the server generates a JWT and returns it to the client, which must then include this token in the Authorization header of each subsequent request to ensure access to protected resources. The token acts as a credential that validates the client’s identity and permissions, allowing the server to verify that the requester is authorized to perform the requested actions without requiring additional login steps each time.

Headers

Configuring JWT Authentication

Specify the authentication type as JWT for using JSON
Web Tokens (JWT).

The Authentication Configuration tab is visible when
the API is in the OPEN/PUBLISHED state.

Select a JWT algorithm from the list of available
options.

Provide the JWT token’s expiration time in hours.

Use the “UPDATE JWT KEYS” button to create or refresh
JWT keys according to the chosen algorithm.

As shown in the image below, JWT keys are generated
according to the chosen algorithm(RS256) when the “UPDATE JWT KEYS” button is clicked.

As shown in the image below, JWT keys are generated
according to the chosen algorithm(HS256) when the “UPDATE JWT KEYS” button is clicked.

Login Using JWT

Below Image Shows the jwt login request in postman

Here’s an example using Python:

import requests
import json

url = "http://localhost:8016/gql_jwt/api/jwt/auth/login"

payload = json.dumps({
"login": "admin",
"password": "admin"
})
headers = {
'Content-Type': 'application/json',
}

response = requests.request("POST", url, headers=headers, data=payload)

print(response.text)

Fetch Data Using JWT
Authentication

Below Image Shows the jwt fetch data request in
postman

Here’s an example using Python:

import requests
import json

url = "http://localhost:8016/gql_jwt"

payload = "{\"query\":\"query MyQuery {\\n    SaleOrder {\\n        id\\n        name\\n    }\\n}\",\"variables\":{}}"
headers = {
'Authorization': 'Bearer eyJ0eXAiOiJKV1QiLCJhbGciOiJIUzI1NiJ9.eyJzdWIiOjIsIm5hbWUiOiJNaXRjaGVsbCBBZG1pbiIsImV4cCI6MTczMDIyNzYwM30.wbcAM5Ps-qvPvLkW-IJX7iODHXQo1Ps6-14Hiq4FClE',
'Content-Type': 'application/json'
}

response = requests.request("POST", url, headers=headers, data=payload)

print(response.text)
